The SGM4865 is a stereo audio power amplifier which operates from 2.6V to 5.5V supply voltage. It can deliver 2.6W into a 4Ω load from 5V supply at THD+N = 1%. It is designed for portable applications. The external gain-setting resistors can configure the unity-gain stable of the device. The SGM4865 has pop/click suppression circuitry, low power consumption shutdown mode and thermal shutdown protection.

The SGM4865 is available in a Green TQFN-4×4-16L package. It operates over an ambient temperature range of -40℃ to +85℃.

FEATURES

• Supply Voltage Range: 2.6V to 5.5V

• 2.6W into 4Ω Load from 5V Supply at THD+N = 10% (Typical, per Channel)

• Shutdown Current: 0.03μA (TYP)

• Excellent PSRR: Direct Connection to Battery

• No Output Coupling Capacitors

• External Gain Configuration Capability

• Pop/Click Suppression Circuitry

• Unity Gain Stable

• Thermal Shutdown Protection

• -40℃ to +85℃ Operating Temperature Range

• Available in a Green TQFN-4×4-16L Package

APPLICATIONS

Cell Phones, PDAs

Multimedia Monitors

Portable and Desktop Computers

Desktops Audio System
