The SGM808B is a low-power and high-accuracy voltage detector. The adjustable threshold range is 1.5V to 6V with increments of 0.1V, which greatly provides application flexibility.

The device has an N-channel open-drain output. It is very suitable for applications in power sequencing, reset sequencing and power switching.

The SGM808B is available in Green SC70-4 (R), SOT-23-5 and SOT-89-3 packages. It is specified over the -40℃ to +125℃ operating junction temperature range.

FEATURES

● Operating Voltage Range: 0.95V to 10V

● High Accuracy Detection: ±1.5% at TJ = +25℃

● Low Power Consumption: 1μA (TYP) at VCC = 3.5V

● Detection Voltage Range: 1.5V to 6V (0.1V Increments)

● Hysteresis Characteristics: 5% (TYP)

● N-Channel Open-Drain Output

● Available in Green SC70-4 (R), SOT-23-5 and SOT-89-3 Packages

APPLICATIONS

Power Sequencing and Reset Sequencing

Power Switching

Automotive Equipment

Portable Equipment

Computers/Servers
